6 Inch Simple Ceiling Mounting (6 inch) without ceiling column EAR-6

6 Inch Simple Ceiling Mounting (6 inch) without ceiling column
EAR-6

Specification

A : Flexible hose
 Ø 150mm, nylon material. Consists of two parts, one
connects to the base connection tube; the other connects
to the extraction hood. Internal with special
adjusting joints,which can adjust the position of
the extraction arm and extraction hood freely.
 Base adapter material : Red fireproof plastic material.
 Base connection tube : Aluminum alloy material, Ø
150mm.

B : Sloping dome extraction hood
 Dimension : Ø150/Ø265 x 420(L)mm
 Hood material : Aluminum alloy
 Damper switch : There is an air flap made of aluminum alloy inside the extraction hood, and
a knob outside to control the air flow.
 Hood cover bar : TPV rubber material to achieve the effect of embellishing and sealing the edge.

C : Ceiling Column
 Dimension : 175Wx 175Dx 750Hmm
175Wx 175Dx 1000Hmm
175Wx 175Dx 1250Hmm
 Material : Iron plate with white power coated
D : Features
The flexible hose can be easily adjusted and bent; the extraction hood can be also moved to
approach the source of pollution and to capture different gases dust avoiding their expansion in the
room. This unit can be easily retracted and positioned after not in use, so as to facilitate the
cleaning of the workplace. Additional, the base of the extraction hose can be 360° rotation and the
extraction hood has a damper device to control the air flow by switching the knob.

Stocks are available, subject to prior sales. Please contact us at sales@biosafetysupplies.com or send us a WhatsApp message at +65 96673290 to confirm the stocks level.

We offer Free Delivery for order value above $200 within mainland Singapore (excluding Islands and ports)
Delivery charge of $20 is applicable for order value less tha $200.

If you're a reseller or considering a bulk purchase quantity, you may request for a special quote. Kindly send us an email at sales@biosafetysupplies.com and we will get back to you within 1 working day.
